AUTEL EVO MAX 4T
The Autel EVO MAX 4T brings powerful technologies and advanced autonomy to professional drone users. The EVO Max 4T assesses complex environments to create real-time 3D flight paths for unparalleled obstacle avoidance. Advanced sensors make flight in GPS unavailable areas possible and the incredible new thermal payload unlocks new object identification and tracking scenarios. With a foldable weather-resistant design - the Autel EVO Max 4T is as portable as it is capable.
AIRCRAFT
Weight: 3.5 lbs (1600g with battery and gimbal included)
Max. Takeoff Weight: 4.41 lbs (1999 g)
Dimensions:
576x660x149 mm (folded, including propellers)
340x407x148 mm (folded, excluding propellers)
257x136x133 mm (unfolded, excluding propellers)
Diagonal Wheelbase: 1.52 ft (464mm)
Max Ascent Speed: 8m/s
Max Descent Speed: 6m/s
Max Horizontal Speed (windless near sea level): 23m/s
Max Service Ceiling Above Sea Level: 23000ft (7000m)
Max Flight Time (windless): 42 minutes
Max Hovering Time (windless): 38 minutes
Max Wind Resistance: 27mph*
*Takeoff and landing can withstand wind speeds up to 27 mph (12 m/s).
IP Rating: IP43
Max Tilt Angle: 35°
Max Angular Velocity:
Pitch: 300°/s; Yaw: 120°/s
Operating Temperature: -4°F to 122°F (-20°C - 50°C)
Operating Frequency: 2.4G/5.2G*/5.8G/900MHz*
GNSS: GPS+Galileo+BeiDou+GLONASS
Transmitter Power (EIRP):
2.4GHz:<33dBm(FCC), <20dBm(CE/SRRC/MIC)
5.8GHz:<33dBm(FCC), <30dBm(SRRC), <14dBm(CE)
5.15-5.25GHz: < 23dBm(FCC/SRRC/MIC)
5.25-5.35GHz:<30dBm(FCC), <23dBm(SRRC/MIC)
Hovering Accuracy:
Vertical:
±0.1 m (Vision System enabled);
±0.3 m (GPS enabled);
±0.15 m (RTK enabled);
Horizontal:
±0.15 m (Vision System enabled);
±0.3 m (GPS enabled);
±0.1 m (RTK enabled);
ZOOM CAMERA (TELEPHOTO)
Sensor: 1/2" CMOS, Effective pixels: 48M
Lens:
Focal length: 11.8-43.3mm (35mm, equivalent: 64-234mm)
Aperture: f/2.8-f/4.8
Exposure Compensation: ±3EV 0.3EV/step
ISO Range:
Normal Mode:
Auto: ISO100 ~ ISO6400
Manual:
Photo: ISO100 ~ ISO12800
Video: ISO100 ~ ISO6400
Shutter Speed:
Photo: 8s ~ 1/8000s
Video: 1s ~ 1/8000s
Max Photo Size: 8000×6000
Max Video Resolution: 7680×4320
WIDE CAMERA
Sensor: 1/1.28 CMOS, Effective pixels: 50M
Lens:
DFOV: 85°
Focal length: 4.5 mm (equivalent: 23 mm)
Aperture: f/1.9
AF motor: 8-wire SMA, PDAF focus
Exposure Compensation: ±3EV 0.3EV/step
ISO Range:
Auto:
Photo: ISO100~ISO6400
Video: ISO100~ISO64000 (Night scene mode: up to ISO64000)
Manual:
Photo: ISO100~ISO12800
Video: ISO100~ISO6400
Shutter Speed:
Photo: 8s ~ 1/8000s
Video: 1s ~ 1/8000s
Max. Video Resolution: 3840×2160
Photo Size: 8192x6144, 4096x3072
THERMAL CAMERA
Thermal Imager: Uncooled VOx Microbolometer
Lens:
DFOV: 64°
Aperture: 13mm
Focus: f/1.2
Infrared Temperature Measurement Accuracy:
26.6~37.4 °F or reading ±3% (using the larger value) @ambient temperature -4°F to 140°F
Video Resolution: 640x512
Photo Size: 640x512
Pixel Pitch: 12 um
Temperature Measurement Method:
Center Measurement, Spot Measurement, Rectangular Measurement
Temperature Measurement Range:
-4°F to 302°F, 32°F to 1022°F (-20°C to 150°C, 0 to 550°C)
Temperature Alert:
High and low temperature alarm thresholds, reporting coordinates and temperature values
LASER RANGEFINDER
Measurement Accuracy: ±3.3ft (1m)
Measuring Range: 3937ft (1200m)
GIMBAL
Mechanical Range:
Pan: -135° to 45°
Tilt: -45° to 45°
Roll: -45° to 45°
Controllable Range:
-90° to 30°
Stable system:
3-axis mechanical gimbal (pan, tilt, roll)
Max Control Speed (pitch): 200°/s
Angular Vibration Range: <0.005°
IMAGE TRANSMISSION
Operating Frequency:
2.4G/5.2G*/5.8G/900MHz*
*5.2GHz is only applicable for FCC, CE, and UKCA regions. 900MHz is only applicable for FCC regions.
Max Transmission Distance (unobstructed, free of interference):
12.4 miles/20km (FCC), 4.9 miles/8km (CE)
Independent Networking: Autel Smart Controller V3
Transmitter Power (EIRP):
2.4GHz:<33dBm(FCC), <20dBm(CE/SRRC/MIC)
5.8GHz:<33dBm(FCC), <30dBm(SRRC), <14dBm(CE)
5.15-5.25GHz: < 23dBm(FCC/SRRC/MIC)
5.25-5.35GHz:<30dBm(FCC), <23dBm(SRRC/MIC)
AUTONOMY
Non-GPS Hovering and Manual Flight:
Indoor: Horizontal error =1.18in (At least have texture at one direction)
Outdoor:
Daytime: Within 1640ft (500m) flight height, horizontal error < 0.01*height
Night: Manual flight is controllable within 328ft (100m) flight height
Non-GPS Return-to-Home:
Within 1640ft (500m) flight height, horizontal error of Return-to-Home point < 11.81in
Automatic Obstacle Rerouting:
High Speed Obstacle Rerouting: Flight speed up to 45mph (20m/s) when Min. safety distance to obstacle is 4.9ft (1.5m)
High Precision Obstacle Rerouting: Flight speed could reach 6.7mph (3m/s) when Min. safety distance to obstacle is 1.64ft (0.5m)
Multi-target Recognition and Tracking:
Target identification types: people, vehicles, boats
Number of targets detected: 64
Comprehensive recognition accuracy: > 85%
MILLIMETER-WAVE RADAR SYSTEM
Frequency: 60Ghz~64Ghz*
*Please fly safely and consult your local laws and regulations.
Size: 1.5x0.55x0.08 in (38x14x2mm) (LxWxH)
Weight: 0.07oz (2g)
EIRP: 18dBm
Sensing Range:
Upward: 5.9~787.4in (0.15~20m)
Downward: 3.9~4724.4in(0.1~120m)
Forward and Backward (Standard/Comfortable): 0.82~98.43ft (0.25~30m)
Forward and Backward (Standard/Comfortable): 0.82~98.43ft (0.25~30m)
FOV:
Horizontal: (6dB): ±60°, Vertical (6dB): ±30°
Speed Measurement Range: ±134mph (60m/s)
Speed Measurement Accuracy: ≤1%
Max. Tracking Target Number: 32
VISUAL SENSING SYSTEM
Obstacle Sensing Range:
Forward/Upward/Downward/Backward/Sideward: 0.2~50m
FOV:
Forward/Backward/Sideward: 60°(H), 80°(V)
Upward/Downward: 360°(H), 190°(V)
AUTEL SMART CONTROLLER V3
Screen: 7.9 inch, 2000nits max. brightness, 2048*1536 resolution
External Battery:
Capacity: 5800mAh
Voltage: 11.55V
Battery Type: Li-on
Energy: 67Wh
Charing time: 120mins
Intelligent Lithium Ion Battery
Operating Time:
3 hours (Max. brightness)
4.5 hours (50% brightness)
Max Transmission Distance (with interference):
12.4 miles/20km (FCC), 4.9 miles/8km (CE)
IP Rating: IP43
Storage: 128G
GNSS: GPS+GLONASS+Galileo+Beidou+NavIC+QZSS
Operating Temperature:
-4°F to 104°F (-20°C to 40°C)
Wi-Fi Protocol:
WiFi Direct, Wi-Fi Display,
802.11a/b/g/n/ac
Support 2 x 2 MIMO Wi-Fi
Operating Frequency:
2.400 - 2.4835 GHz;
5.150 - 5.250GHz;
5.725 ? 5.850 GHz
Transmitter Power (EIRP):
2.400 - 2.4835 GHz
FCC/CE:=20dBm
5.150 - 5.250GHz
FCC:=17dBm
5.725 ? 5.850 GHz
FCC:=17dBm
CE:=14dBm
AIRCRAFT BATTERY
Capacity: 8070mAh
Voltage: 14.88V
Battery Type: LiPo 4S
Energy: 120wh
Net Weight: 1.15 lbs (520g)
Charging Temperature:
41°F to 113°F (5°C to 45°C)
When the temperature is lower than 10°C (50° F), the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery.
Hot Swap: Supported
